Standard
Products
|
Part No. |
Dimension |
Application |
Coatings |
|
RTP0410 |
4x4x10mm
|
EO @ 1064 nm
|
AR@ 1064nm, Au on sides |
|
RTP0420 |
4x4x20mm
|
EO @ 1064 nm
|
AR@ 1064nm, Au on
sides |
| RTP0607 |
6x6x7mm |
EO @ 1064 nm
|
AR@ 1064nm, Au on
sides |
Specifications for finished RTP
|
Transmitting wavefront distortion: less than
λ/8 @ 633 nm
|
|
Dimension tolerance: (W +/- 0.1 mm) x (H +/- 0.1
mm) x (L + 0.2 mm/-0.1mm) |
|
Clear aperture: > 90% central area |
|
Flatness:
λ/8 @ 633 nm
|
|
Scratch/dig: 10/5 to MIL-O-13830A |
|
Parallelism: better than 20 arc seconds |
|
Perpendicularity: 30 arc minutes |
|
Angle
tolerance: Δθ < +/- 0.25o,
Df < +/-0.25o
|
Coatings
Standard anti-reflection
coatings at the entrance/exit sides are available. Gold coatings may be
deposited on the sides for HV electrodes. Other coatings are also available
upon request.
|
